Phased array instruments and ability to define anisotropic velocity?
-
Phased array instruments and ability to define anisotropic velocity?
Does anyone know of any PAUT equipment that allows you to define velocity as a function of angle? I believe that Olympus PipeWIZARD V4 has this capability, but beyond that I’m not aware of any regular sort of, “field portable” PAUT set that permits you define velocity as a function of angle (a “velocity vector”, if you will).
Last year I came across this problem first hand while inspecting welds on TMCP pipeline steel. Ed Ginzel and I got a sample, and figured out a very simple way to calibrate for it using two phased array probes in pitch-catch, placed on the pipe material. It was much more common than we thought. I fear they may be many PAUT crews out there looking at “melting S-scans”, and plotting defects incorrectly. This is something that we hope (one day ) to be integrated into field portable PAUT equipment (hint hint my PAUT OEMs!).
The first paper explains the procedure:
https://www.ndt.net/article/ndtnet/papers/Calibration_for_Anisotropic_Effects_on_Shear_Wave_Velocity_for_Improvements_of_Weld_Inspections_in_TMCP_Steels.pdfThen we published two more papers because we simply couldn’t stop ourselves (too interesting!):
https://www.ndt.net/article/ndtnet/papers/Visualisation_of_Acoustic_Birefringence.pdfI also did a video explaining the simple calibration setup:
https://youtu.be/aPxKdGmMUmM -
